Design guidelines for Selective Laser Sintering (SLS)

This article features common guidelines for designing parts and components for SLS printing technique.

  • Dimensional accuracy: ± 0,25mm + ± 0,1mm/100mm
  • Max size: 320 x 320 x 600mm
  • Min wall thickness: 1mm
  • Clearance for functional structures (joints etc.): 0,5mm
  • Min detail: 0,3mm

Wall thickness

The recommended wall thickness is 1 mm. Structures smaller than this are very fragile and may not withstand the post processing stage where the excess powder is removed.

Clearance

The recommended clearance when constructing complex functional structures such as joints is 0.5 mm. In the production phase some powder stays between the parts and must be removed after finishing. If the clearance is too small the powder will compress and possibly even partially melt making it difficult to remove the parts.

Inside and outside texts and labels

Inside and outside texts and labels are possible to print depending on the font size, depth/hight of the text and the orientation when printing. Consult our experts for more information.

Warping

Large thin areas may warp during cooling process. The warping effect is minimised with good design and production management.

Materflow designs and produces 3D printed metal and plastic parts for industrial use. We also help our customers develop and implement 3D printing into their design and engineering processes.
